Eilersen TL 101 Digital Weighing Transmitter Series
Price: Contact
Brand: Eilersen Vietnam
Category: Thiết bị đo lường & Kiểm tra
Supplier: AnhNghiSon
Origin: Denmark
0911472255The Eilersen TL 101 digital weighing transmitter and load cell interface series—encompassing the specialized configuration variants TL 101A, TL 101A-T, and TL 101B—represents a premier line of high-performance industrial signaling components meticulously engineered and constructed in Denmark by Eilersen Electric. Operating as a centralized computational digitization module, the TL 101 series is responsible for aggregating high-resolution raw digital data packages directly from Eilersen's proprietary digital capacitive load cells. Upon signal receipt, the integrated hardware processes advanced digital filtration algorithms designed specifically to eliminate environmental mechanical background interferences (such as rapid dynamic fluid agitation from tank mixers, dynamic wind stress on silos, processing vibrations, or thermal pipeline expansion stresses). Once data refinement is complete, the module streams pristine, synchronized weight values continuously to backbone automation systems including central PLCs, industrial PCs, or comprehensive plant SCADA supervisor nodes.
The functional allocation across these specific model variants ensures great adaptability for industrial automation design engineers: the standard "TL 101A" model supplies a highly stable, backbone communication baseline; the "TL 101A-T" variant incorporates specialized thermal-tracking electronic compensations or dedicated structural terminal blocks to guarantee flawless execution inside control enclosures subject to volatile ambient thermal shifts; whereas the "TL 101B" model integrates customized internal firmware enhancements or optimized hardware layouts tailored for specialized fieldbus architectures or high-frequency data refresh rates.
Regarding hardware architecture, the TL 101 series features a highly compact, rugged industrial form factor engineered specifically for rapid snap-on mounting on standardized DIN-rail profiles inside electrical switchboards, optimizing space and streamlining terminal wiring layouts. The modules allow multi-channel digital load cell connections directly without demanding traditional external mechanical analog junction boxes, completely bypassing the risks of signal attenuation caused by moisture ingress or loose field contacts. The output bus adaptability is comprehensive, interfacing smoothly with prevailing industrial PLC networks like Siemens, Rockwell, Omron, and Mitsubishi. Furthermore, this series fully leverages Eilersen's absolute factory-calibrated matrix, operating via a true "Plug-and-Play" (Calibration-free) deployment matrix. In the event of system maintenance or field swapping, the new transmitter module can be deployed instantly on-site without requiring massive physical dead-weights to re-calibrate the industrial weighing node, drastically mitigating production line downtime and generating exceptional long-term economic dividends for modern processing plants.
• Manufacturer: Eilersen Electric Digital Weighing Technology A/S
• Country of Origin: Denmark
• Product Type: Digital Load Cell Interface Module / Digital Weighing Transmitter
• Integrated Model Classifications within the Series:
- Eilersen TL 101A (Standard Industrial Version)
- Eilersen TL 101A-T (Temperature Optimized / Specialized Terminal Configuration)
- Eilersen TL 101B (Upgraded Firmware / Advanced Communication Architecture)
• Mounting Profile: Standard industrial DIN-rail snap-on mounting architecture
• Enclosure Material: Heavy-duty, high-insulation, impact-resistant thermal polymer housing conforming to European standards
• Load Cell Interfacing Capacity: High-speed multi-channel direct connection matrix designed exclusively for Eilersen digital capacitive load cells
• Calibration Calibration Parameters: 100% pre-calibrated factory specifications from Denmark, absolute calibration-free / Plug-and-Play deployment
• Digital Filtration Matrix: Integrated adjustable digital low-pass filters engineered to cancel mechanical structural agitation and dynamic plant mixer vibration
• Sampling Speed & Refresh Frequency: Ultra-fast sampling cycles ensuring real-time data integrity for dynamic checkweighing and process dosing loops
• Automation Interfacing Suitability (via Gateway combinations): Smooth integration capabilities with Profinet, Profibus DP, EtherNet/IP, Modbus TCP/IP, EtherCAT, DeviceNet, RS485, and legacy Analog outputs (4-20mA / 0-10V)
• Power Supply Requirements: 24Vdc ± 10% featuring integrated reverse polarity and overvoltage protection circuits, low power consumption matrix
• Termination Mechanics: Heavy-duty screw terminal blocks for high mechanical security and quick field servicing disconnects
• Ambient Operating Temperature Range: -20°C to +50°C, fully optimized for continuous 24/7 processing inside tough industrial cabinet environments
