Leuze HT46CI-2N-M12 – High-Performance Diffuse Sensor with Background Suppression
Leuze, a trusted leader in industrial sensor technology, presents the HT46CI-2N-M12 — a powerful diffuse (proximity) sensor with background suppression that delivers reliable detection even in challenging environments and supports long-range applications up to 3 meters.
Key Features
-
Diffuse detection with background suppression
The sensor reliably detects objects while suppressing the background — ideal when the background is complex, reflective, or variable. -
Extended detection range
-
White (90% reflectivity): 0.005 to 3 m
-
Gray (18%): 0.02 to 2 m
-
Black (6%): 0.05 to 1.5 m
-
-
Infrared LED light source
Uses a pulsed IR LED (~860 nm) to ensure stable performance. -
Fast switching & response
-
Switching frequency up to 250 Hz
-
Response time: ~2 ms
-
-
Robust electronics
-
Supply voltage: 10–30 V DC
-
Protection circuitry includes reverse polarity, short circuit & transient protection.
-
Dual NPN switching outputs: one for “light switching,” one for “dark switching.”
-
-
Industrial-grade design
-
Connector: M12, 4-pin
-
Housing: Plastic (PC-PBT) with plastic / PMMA lens cover
-
Compact size: 20.5 × 76.3 × 44 mm; weight ~60 g.
-
-
Durable & reliable
-
Operating temperature: –40 °C to +60 °C
-
Protection rating: IP67 and IP69K, making it resistant to harsh, dusty, or wet industrial environments.
-
Long life expectancy: up to ~100,000 h at 25 °C.
-
-
User-friendly adjustment
Features a multi-turn potentiometer for easy range adjustment. -
Status indicators
Equipped with LEDs to indicate “ready” and “reflection” status.
