Interconnection cable KSS ET-M12-4A-RJ45-A-P7-050 Leuze Vietnam



The Leuze KSS ET‑M12‑4A‑RJ45‑A‑P7‑050 is a high-performance industrial Ethernet cable designed for reliable data transmission in harsh industrial environments. Featuring a D-coded M12 connector (female) on one end and a fully shielded RJ45 male on the other, this 5-meter cable ensures secure, stable, and noise-free connections between industrial sensors, controllers, and automation devices.




⚙️ Key Specifications

  • Connection 1: M12 female (4-pin, D-coded)

  • Connection 2: RJ45 male, shielded

  • Cable length: 5,000 mm

  • Cable type: 4-wire, shielded

  • Cable sheath: PUR, halogen-free, silicone-free, oil-resistant, chemical-resistant

  • Outer diameter: Approx. 6.7 mm

  • Rated voltage: Max. 60 V DC

  • Protection class:

    • M12 side: IP65/IP67 (when properly connected)

    • RJ45 side: IP20

  • Temperature range:

    • Fixed installation: –30 °C to +70 °C

    • Flexible use: –10 °C to +70 °C

  • Bending resistance: >2 million cycles in energy chains

  • Wire cross-section: 0.34 mm² (AWG 22)

  • Weight: Approx. 289 g


✅ Why Choose This Cable?

  • Industrial-Grade Durability: Built to endure oil, grease, abrasion, and mechanical stress in high-performance manufacturing environments.

  • Reliable Ethernet Communication: Shielded cable with optimized contact layout ensures high-speed data transfer with minimal interference.

  • Flexible for Dynamic Applications: Perfect for use in cable tracks, robotics, and moving machinery thanks to high bending endurance.

  • Plug-and-Play: Ready for immediate use in industrial setups using M12 and RJ45 interfaces.
