Connection cable KD S-M12-CA-P1-050 Leuze Vietnam





The KD S‑M12‑CA‑P1‑050 by Leuze is a robust, industrial-grade connection cable featuring a 12-pin M12 female axial connector with pigtail open end. Designed for harsh environments, this 5-meter PUR cable ensures secure and reliable signal transmission in automation systems, sensors, and machine safety connectivity tasks.


🔍 Key Technical Features

  • Connector Type: M12, 12-pin female (A-coded), axial orientation

  • Cable Length: ~5,000 mm (5 m)

  • Conductor Count and Size: 12 cores, 0.14 mm² each (AWG 26)

  • Sheathing Material: PUR, black, halogen- and silicone-free; abrasion, oil, and chemical-resistant per VDE 0472 pt 803 test B

  • Shielded: Yes

  • Operating Temperatures: Flexible: –25 °C to +80 °C; Fixed: –40 °C to +80 °C

  • Bending Cycles: Up to 5 million cycles, suitable for drag-chain installations (≤3.3 m/s, ≤5 m/s²)

  • Protection Rating: IP65 / IP67 when connected properly

  • Weight: Approx. 270 g


✅ Benefits & Advantages

  • Reliable Industrial Connectivity: The A-coded 12-pin M12 connector supports power and signal transmission in demanding setups such as safety sensors, control systems, and automation equipment.

  • Durable & Flexible Cable: PUR sheath is resistant to abrasion, oils, chemicals, and microbe attack, making it ideal for industrial robotics, machine tools, and conveyor systems.

  • Designed for Heavy Usage: With high bending endurance and wide temperature tolerance, the cable remains durable even in continuous motion or harsh production conditions.

  • Easy Integration: Open-end conductor tails allow customized termination during installation, supporting both flexible and fixed configurations.

  • Certified Quality: Free from harmful substances (halogen, silicone), tested to UL/CSA and VDE standards.
