Electromagnetic Flow Meter FT-3400-100-1C32 Onicon Vietnam
Price: Contact
Brand: ONICON
Category: Flow meter
Supplier: ansvietnam
Origin: USA
0911472255Electromagnetic Flow Meter FT-3400-100-1C32 Onicon Vietnam
ONICON FT-3400 Series – Insertion Electromagnetic Flow Meter for Conductive Liquids
The FT-3400 from ONICON is a high-performance, insertable electromagnetic flow meter designed for measuring conductive liquid flows (e.g., water, water/glycol, condenser water) across HVAC, municipal, and process systems. Featuring ONICON’s patented hot-tap insertion, field-calibrated accuracy, and no-moving-parts design, the FT-3400 ensures ongoing reliability with zero flow interruption.
🔧 Key Features
-
Hot-Tap Insertion Design
Install or remove the sensor live—no shutdown required. Ideal for retrofitting existing piping systems. -
Best-In-Class Accuracy
Factory wet-calibrated and accurate to ±1.0% of reading (range 2–20 ft/s), with sensitivity down to ±0.02 ft/s at low flow rates. -
Versatile Output Signals
Includes isolated analog (4–20 mA, 0–10 V or 0–5 V), high resolution frequency (0-500 Hz), scalable pulse, flow direction contact closure, and master alarm signal. -
Robust & Maintenance-Free
No moving parts. Proprietary MEMS sensor with continuous auto-zero ensures long-term stability. -
Wide Installation Range
Compatible with pipe sizes from 1¼″ to 72″ (DN32–DN1800), conductive liquids ≥25 µS/cm, temperatures up to ~93 °C, and pressures up to 27.6 bar. NEMA 4 enclosure with 10-ft cable. -
Plug-and-Play Ready
Pre-programmed at factory—no field setup required. Simply insert and the meter is operational from day one.
🎯 Typical Applications
-
HVAC hydronic systems: chilled water, heating hot water, condenser water loops
-
Domestic and municipal water systems
-
Process water and glycols in industrial plants
-
Thermal storage, boiler-feed, and bidirectional bypass loops
-
Retrofit installations where shutdowns are unacceptable
