Torque Tester EZ-TorQ III 100i Checkline Vietnam

Highly portable and user friendly, this battery-powered torque validation hub can be easily carried around the assembly line to spot check tools as part of a QA program or used at assembly stations for quick and easy torque tool validation and calibration. The new smartphone like touch-screen interface breaks down barriers and ensures quick and easy torque tool validation and calibration. EZ-TorQ digital torque tester features a built-in transducer. The easy-to-use torque analyzer is ideal for all small hand tools & non-impacting power tools.
The EZ-TorQ III is not for use in testing Impact or Pulse type tools.

Features

• Supplied with an ISO 17025 Certification of Calibration
• Three operating modes: Track, Peak, and First Peak
• Seven units of torque measurements: (ozf.in, lbf.in, lbf.ft, cN.m, N.m, kgf.m, kgf.cm)
• Vivid full color, smartphone-like touchscreen interface
• Virtually unlimited data point storage with swappable SD card memory
• Flash memory allows upgrades to be done by the user in the field & internet through the RS-232 port
• Ability to download readings to PC via RS-232 or via USB
• Features Go / No Go LEDs that illuminate when high or low tolerance setting is achieved or out of tolerance
• Accuracy ± 0.5% of reading from 20% to 100% of full scale
• Includes Spring Run Down Fixture for use when testing power tools
• Supplied in fitted carrying case
• On board software with SPC analysis
