SIPLUS I/O modules 6AG1131-6BH01-7BA0 SIEMENS Vietnam

Siemens 6AG1131-6BH01-7BA0 – High-Performance Digital Input Module for Harsh Industrial Environments

The Siemens 6AG1131-6BH01-7BA0 is a 16-channel digital input module (DI 16x 24 V DC) from the SIPLUS ET 200SP family, designed for reliable operation in extreme and harsh environments. With conformal coating protection and a wide operating temperature range from –40 °C to +70 °C, this module ensures superior performance even in environments exposed to humidity, dust, or chemicals.

🔧 Key Features

• 16 digital input channels (24 V DC, type 3 according to IEC 61131)

• Wide voltage range: 19.2 – 28.8 V DC with reverse polarity protection

• Configurable input delay: 0.05 ms – 20 ms for flexible application tuning

• Integrated diagnostics: wire break detection, voltage monitoring, and LED status indicators

• Compact design: only 15 mm wide, 73 mm high, and 58 mm deep; weight approx. 28 g

• Extreme environment protection:

  • Operating temperature: –40 °C to +70 °C

  • Conformal coated against moisture, dust, and chemicals

  • Test insulation voltage: 707 V DC

• Mechanical coding and automatic addressing for easy configuration

• Fully compatible with TIA Portal / STEP 7 engineering tools

✅ Benefits

• Rugged and reliable – ideal for use in outdoor, chemical, or dusty industrial areas

• Advanced diagnostics reduce downtime and simplify maintenance

• Flexible response time configuration ensures stable operation in dynamic systems

• Seamless integration with ET 200SP distributed I/O systems

• Compact footprint saves valuable control cabinet space
