The MAS and MSCP Series Moisture Absorbers and Compact Sample Conditioning Panels are engineered by Bühler Technologies GmbH – a globally recognized German manufacturer specializing in industrial gas analysis and sample conditioning systems. These device series play a vital role in eliminating residual moisture, deeply drying sample gas streams, and preventing liquid carry-over prior to sample entry into delicate gas analyzers.

In Continuous Emission Monitoring Systems (CEMS) and industrial process control, moisture and liquid condensate represent the greatest threat to analytical sensors (such as NDIR, UV, and Paramagnetic analyzers). Water vapor not only causes spectral interference in optical measurements but also combines with acidic gas components (SO2, NO2, HCl) to form highly corrosive acid mists that destroy expensive analyzer cells. The Bühler MAS & MSCP suite provides a complete two-tier protection framework:

1. Bühler MAS Series (Moisture Absorber System): A specialized absorption column line utilizing industrial desiccant media (such as color-indicating Silica Gel, Molecular Sieve, or inert chemical absorbers). After primary cooling, the sample gas passes through the MAS unit to strip away trace micro-moisture, driving the sample dew point down to extremely low levels. The transparent high-grade glass cylinder allows maintenance personnel to easily inspect desiccant color change for timely replacement.
2. Bühler MSCP Series (Mini/Mobile Sample Conditioning Panel): A compact turnkey panel system designed for cabinet mounting. The MSCP integrates a moisture separator trap, fine particulate filter, flow control valve, and moisture detection sensor. In the event of abnormal condensate breakthrough bypassing the primary gas cooler, the MSCP immediately trips an alarm relay to shut off gas flow, safeguarding downstream analyzers from liquid damage.

All gas-wetted components are constructed from premium corrosion-resistant materials including Borosilicate Glass, PTFE, PVDF, and 316L Stainless Steel. Featuring compact dimensions, high operational reliability, and mounting versatility, the Bühler MAS & MSCP suite is the preferred choice for CEMS shelters, thermal power plants, cement factories, refineries, chemical plants, and gas analytical laboratories.

• Manufacturer: Bühler Technologies GmbH
• Product Lines: MAS Series & MSCP Series
• Device Types: Moisture Absorber Column & Compact Conditioning Panel (Moisture Absorber & Mini Sample Conditioning Panel)
• Country of Origin: Germany
• Desiccant Media (MAS Series): Color-indicating Silica Gel / Molecular Sieve / Calcium Sulfate
• Absorber Cylinder Capacity (MAS): 0.25 L to 1.0 L (Configurable column sizes)
• Sample Gas Flow Rate Capacity: Up to 120 Nl/h to 250 Nl/h
• Max. Operating Pressure: Up to 3 bar - 5 bar
• Post-Treatment Dew Point: Down to <-20°C to -40°C (MAS Deep Drying)
• Moisture Protection (MSCP Series): Integrated Moisture Detector with Relay alarm output
• Fine Particulate Filter (MSCP): Integrated PTFE / Ceramic element with 2 µm porosity
• Wetted Materials: Borosilicate Glass, PVDF, PTFE, Viton (FKM), 316L Stainless Steel
• Ambient Operating Temperature: +5°C to +50°C
• Max. Inlet Sample Gas Temperature: +80°C
• Status & Relay Outputs (MSCP): Condensate breakthrough alarm (Relay contacts 230V AC, 1A)
• Gas Connection Fittings: G1/4" or NPT 1/4" female threads (PVDF/PTFE/SS tube fittings)
• Net Weight: Ultra-lightweight from 0.8 kg (MAS column) to 3.5 kg (MSCP Panel)
