The Shilla Fire SL-13AN is a heavy-duty, high-capacity master stream fire monitor nozzle engineered and manufactured by Shilla Fire Co., Ltd. (Korea). Specifically designed for heavy-hazard industrial and municipal firefighting applications, this nozzle seamlessly mounts to fixed station monitors, elevated master streams, mobile trailer units, and industrial fire apparatus.

The core advantage of the SL-13AN lies in its responsive manual pattern control mechanism. Operators can adjust the discharge pattern smoothly from an intensive, long-reach Straight Stream designed for deep fire penetration and long-distance reach, to a dense Wide Fog pattern. The wide-angle fog curtain provides rapid cooling, accelerates fuel vapor suppression, and establishes an effective thermal radiation barrier to protect firefighting crews and adjacent critical assets.

Precision-engineered from corrosion-resistant cast Bronze/Brass or hard-anodized marine-grade aluminum alloy, the Shilla Fire SL-13AN ensures continuous operational reliability under high hydrodynamic loads and harsh chemical or saline atmospheric exposure. Compatible with fresh water, seawater, and aqueous foam concentrates (AFFF, AR-AFFF), it represents an industry-standard solution for petroleum refineries, offshore platforms, bulk fuel depots, and chemical handling complexes worldwide.

• Manufacturer: Shilla Fire Co., Ltd. (Korea)
• Product Series: Master Stream / Fire Monitor Nozzles
• Model: SL-13AN
• Device Type: Adjustable Fog & Straight Stream Fire Nozzle
• Media Compatibility: Firefighting water and foam concentrates (AFFF / AR-AFFF)
• Nominal Working Pressure: 7.0 bar (0.7 MPa / 100 psi)
• Hydrostatic Test Pressure: 20 bar (2.0 MPa)
• Nominal Flow Rate: 500 – 1,000 GPM (approx. 1,900 – 3,800 LPM adjustable)
• Effective Throw Distance (Straight Stream): 45 m – 65 m (at 7 bar operating pressure)
• Maximum Fog Pattern Angle: Up to 120°
• Inlet Connection: 2.5" Female Swivel (NH / BSP / Storz options available)
• Pattern Adjustment: Heavy-duty ribbed rubber bumper sleeve
• Body Material: Marine-grade corrosion-resistant Cast Bronze / Brass or Hard-Anodized Aluminum
• Spinning Teeth: Stainless steel or precision machined fixed teeth
• Net Weight: Approx. 4.5 kg – 7.8 kg (depending on material selection)
• Certifications & Standards: KFI Approved (Korea Fire Institute), NFPA 1964 compliant
