The Installed Lighting Series manufactured by Wolf Safety Lamp Company Ltd (United Kingdom) comprises top-tier fixed hazardous area LED lighting fixtures certified to ATEX and IECEx standards for Zone 1, Zone 2 (Gas) and Zone 21, Zone 22 (Combustible Dust). This comprehensive industrial portfolio includes Linear Luminaires (LMX), High-Output Floodlights (LFX), Highbay Luminaires (LHX), Wall-Mounted Bulkheads (LBX), and Directional Linear Optics (DLO), delivering an optimized illumination solution for oil refineries, chemical plants, offshore platforms, and heavy industrial facilities.

COMPLETE DIRECTORY OF 32 PRODUCT CODES IN THE INSTALLED LIGHTING RANGE:

I. FIXED LINEAR LED LUMINAIRES (LMX SERIES):
1. Product Code: LMX2S-L-50
- Product: Fixed Linear LED Luminaire (Standard, Size 2, 5000K)
- Details: Size 2 housing (~600mm), natural white 5000K color temperature, standard L distribution.

2. Product Code: LMX2S-L-60
- Product: Fixed Linear LED Luminaire (Standard, Size 2, 6000K)
- Details: Size 2 housing, daylight white 6000K providing high visual contrast.

3. Product Code: LMX4S-L-50
- Product: Fixed Linear LED Luminaire (Standard, Size 4, 5000K)
- Details: Size 4 housing (~1200mm), high lumen output, 5000K color temperature.

4. Product Code: LMX4S-L-60
- Product: Fixed Linear LED Luminaire (Standard, Size 4, 6000K)
- Details: Size 4 housing, 6000K color temperature, ideal replacement for traditional twin fluorescent tubes.

5. Product Code: LMX2E-L-60
- Product: Linear LED Emergency Luminaire (Size 2, 6000K)
- Details: Integrated emergency battery backup automatically illuminating during power failure, size 2, 6000K.

6. Product Code: LMX4E-L-60
- Product: Linear LED Emergency Luminaire (Size 4, 6000K)
- Details: Size 4 (1200mm) emergency version with heavy-duty backup battery, 6000K.

7. Product Code: LMX2S-F-50
- Product: Fixed Linear LED Luminaire F-Optics (Size 2, 5000K)
- Details: Engineered F-optic distribution for uniform beam spread, size 2, 5000K.

8. Product Code: LMX2S-F-60
- Product: Fixed Linear LED Luminaire F-Optics (Size 2, 6000K)
- Details: F-optic beam profiling, size 2, crisp 6000K white light.

9. Product Code: LMX4S-F-50
- Product: Fixed Linear LED Luminaire F-Optics (Size 4, 5000K)
- Details: High-output size 4 model with broad F-optic beam coverage, 5000K.

10. Product Code: LMX4S-F-60
- Product: Fixed Linear LED Luminaire F-Optics (Size 4, 6000K)
- Details: Size 4 body with F-optic beam distribution, 6000K.

11. Product Code: LMX2E-F-60
- Product: Linear LED Emergency Luminaire F-Optics (Size 2, 6000K)
- Details: Size 2 emergency battery unit combined with F-optic spread, 6000K.

12. Product Code: LMX4E-F-60
- Product: Linear LED Emergency Luminaire F-Optics (Size 4, 6000K)
- Details: High-capacity size 4 emergency luminaire with F-optic distribution, 6000K.

II. FIXED INDUSTRIAL LED FLOODLIGHTS (LFX SERIES):
13. Product Code: LFX1S-12-55
- Product: Industrial Fixed LED Floodlight (Size 1, 12 LEDs, 5500K)
- Details: Compact size 1 body, 12 LED modules, 5500K color temperature.

14. Product Code: LFX1S-12-65
- Product: Industrial Fixed LED Floodlight (Size 1, 12 LEDs, 6500K)
- Details: Size 1 enclosure, 12 LED modules, 6500K crisp cool daylight.

15. Product Code: LFX1S-16-45
- Product: Industrial Fixed LED Floodlight (Size 1, 16 LEDs, 4500K)
- Details: Size 1 body with 16 LED modules for higher luminous flux, 4500K warm-neutral white.

16. Product Code: LFX1S-16-55
- Product: Industrial Fixed LED Floodlight (Size 1, 16 LEDs, 5500K)
- Details: Size 1 body, 16 LED modules, 5500K industrial standard beam.

17. Product Code: LFX2S-24-50
- Product: Industrial Fixed LED Floodlight (Size 2, 24 LEDs, 5000K)
- Details: Heavy-duty size 2 housing, 24 LED modules, broad flood pattern, 5000K.

18. Product Code: LFX2S-24-60
- Product: Industrial Fixed LED Floodlight (Size 2, 24 LEDs, 6000K)
- Details: Size 2 chassis, 24 LED modules, 6000K covering wide operational decks.

19. Product Code: LFX2S-32-50
- Product: Industrial Fixed LED Floodlight (Size 2, 32 LEDs, 5000K)
- Details: Maximum power with 32 LED modules, size 2 housing, 5000K.

20. Product Code: LFX2S-32-55
- Product: Industrial Fixed LED Floodlight (Size 2, 32 LEDs, 5500K)
- Details: Top-tier size 2 floodlight, 32 LED modules, 5500K, ideal for offshore platform illumination.

III. HIGHBAY LED WAREHOUSE LUMINAIRES (LHX SERIES):
21. Product Code: LHX1S-12-55
- Product: Highbay LED High-Ceiling Luminaire (Size 1, 12 LEDs, 5500K)
- Details: Suspended highbay luminaire with die-cast heat sink, 12 LED modules, 5500K.

22. Product Code: LHX1S-12-65
- Product: Highbay LED High-Ceiling Luminaire (Size 1, 12 LEDs, 6500K)
- Details: Explosion-proof size 1 highbay, 12 LED modules, 6500K.

23. Product Code: LHX1S-16-45
- Product: Highbay LED High-Ceiling Luminaire (Size 1, 16 LEDs, 4500K)
- Details: High-intensity 16 LED modules, 4500K glare-reducing color temperature.

24. Product Code: LHX1S-16-55
- Product: Highbay LED High-Ceiling Luminaire (Size 1, 16 LEDs, 5500K)
- Details: High-efficiency size 1 highbay, 16 LED modules, 5500K.

25. Product Code: LHX2S-24-50
- Product: Highbay LED High-Ceiling Luminaire (Size 2, 24 LEDs, 5000K)
- Details: Large size 2 highbay for mounting heights over 10 meters, 24 LEDs, 5000K.

26. Product Code: LHX2S-24-60
- Product: Highbay LED High-Ceiling Luminaire (Size 2, 24 LEDs, 6000K)
- Details: Size 2 highbay, 24 LED modules, crisp 6000K white light.

27. Product Code: LHX2S-32-50
- Product: Highbay LED High-Ceiling Luminaire (Size 2, 32 LEDs, 5000K)
- Details: Flagship industrial highbay with 32 LED modules for large-scale warehouses, 5000K.

IV. WALL-MOUNTED BULKHEADS (LBX SERIES) & OPTICAL ACCESSORIES:
28. Product Code: LBXS-L-59
- Product: Fixed LED Bulkhead Luminaire (Standard, 5900K)
- Details: Impact-resistant wall/ceiling bulkhead for stairwells and walkways, 5900K.

29. Product Code: LBXS-L-65
- Product: Fixed LED Bulkhead Luminaire (Standard, 6500K)
- Details: Fixed bulkhead offering cool daylight 6500K, superior dust and water ingress protection.

30. Product Code: LBXE-L-59
- Product: LED Bulkhead Emergency Luminaire (5900K)
- Details: Features internal emergency battery backup, wall-mounted for escape path safety, 5900K.

31. Product Code: LBXN-L-59
- Product: Fixed LED Bulkhead Luminaire N-Class (5900K)
- Details: Specialized bulkhead designed for auxiliary industrial utility spaces, 5900K.

32. Product Code: DLO
- Product: Directional Linear Optics Range
- Details: Advanced directional optical lens technology that focuses light precisely on target work surfaces, minimizing glare and light wastage.

• Manufacturer: Wolf Safety Lamp Company Ltd
• Origin: United Kingdom
• Explosion-Proof Certification: ATEX / IECEx Certified
• Hazardous Area Classification: Zone 1, Zone 2 (Gas/Vapours) & Zone 21, Zone 22 (Combustible Dusts)
• Voltage Range: 110V – 254V AC/DC (50/60Hz)
• Series Classification:
  - LMX Series (Linear): Size 2 (~600mm) & Size 4 (~1200mm) | Standard / Emergency / F-Optic options | CCT: 5000K, 6000K
  - LFX Series (Floodlight): Size 1 (12/16 LEDs) & Size 2 (24/32 LEDs) | CCT: 4500K, 5000K, 5500K, 6000K, 6500K
  - LHX Series (Highbay): Suspended ceiling mount | Size 1 (12/16 LEDs) & Size 2 (24/32 LEDs) | High-lumen packages
  - LBX Series (Bulkhead): Wall/ceiling mount | Standard LBXS, Emergency LBXE, Auxiliary LBXN | CCT: 5900K, 6500K
  - DLO (Directional Linear Optics): Precision directional beam-shaping optical modules
• Housing Materials: Marine-grade corrosion-resistant powder-coated aluminium / Stainless Steel / High-impact tempered glass
• Ingress Protection (IP Rating): IP66 / IP67 (Dust-tight and protected against high-pressure water jets)
• Temperature Class: T4 / T5 / T6
• LED Service Life: > 100,000 operational hours
• Ambient Operating Temperature: -50°C to +55°C
• Typical Applications: Fixed lighting in petrochemical plants, offshore drilling platforms, chemical warehouses, power substations, and heavy manufacturing facilities.
